Everything posted by Josh

  1. You need to select the correct shader. https://www.leadwerks.com/learn?page=Tutorials_Editor_Materials It's easiest to use the "generate materials" menu item or right-click on the diffuse texture and create a material from that.
  2. Josh

    Very. Big. Worlds.

    Another interesting thing is that at that scale, the curvature of the Earth (or wherever you are) has to be taken into consideration. Stay tuned...
  3. Josh

    Very. Big. Worlds.

    @Thirsty Panther Procedural or GIS data.
  4. Josh

    Very. Big. Worlds.

    You might have seen this graphic comparing the size of the world in different games. I've played Fuel, and never reached the end of the world in that game. You can drive for a very long time on those roads. We want to use the new engine for realistic simulations of air and ground movements. At normal cruising altitude of a commercial airliner, the pilot has a view range of about 400 kilometers. The image below shows that area (800 x 800 km). You can see the areas of the biggest games ever fit neatly into the corner of just our visible area. The gray space above is not the total world size, it is just the area you can see at once from high altitude. The total world size is about 50 times bigger. This is what I am working on now.
  5. Current plan is that the terrain will not be "infinite" but it will be so big you will never reach the end.
  6. Have you seen the example here? https://www.leadwerks.com/learn?page=API-Reference_Object_Widget_Button
  7. Version 5 is built around Unicode, using std::wstring everywhere. Leadwerks 4 supports Windows and Linux. The next version is planned to support Windows / Mac / Linux, and other platforms may be as well, since Vulkan makes this all a bit easier. Honestly, Windows is 99% of the PC market, and you will actually get a lower review score on Steam if you include a Linux build, because those users will disproportionately have compatibility problems and blame you it, (regardless of what engine or middleware you use). If you release a build for Linux I don't recommend making it available on Steam. You should probably be thinking more in terms of how many digital PC stores you can get a Windows build in, as that will actually make a significant difference in your sales. (Discord, GOG, Amazon, etc.) The Humble Store is now giving us about a third of our new sales, and I think Steam is going to become more insignificant in the future.
  8. Josh

    Multi-monitor Support

    Also added DISPLAY_VIRTUAL to get the entire virtual screen area.
  9. Big update available now for Turbo Engine beta.

  10. A huge update is available for Turbo Engine Beta. Hardware tessellation adds geometric detail to your models and smooths out sharp corners. The new terrain system is live, with fast performance, displacement, and support for up to 255 material layers. Plugins are now working, with sample code for loading MD3 models and VTF textures. Shader families eliminate the need to specify a lot of different shaders in a material file. Support for multiple monitors and better control of DPI scaling. Notes: Terrain currently has cracks between LOD stages, as I have not yet decided how I want to handle this. Tessellation has some "shimmering" effects at some resolutions. Terrain may display a wire grid on parts. Directional lights are supported but cast no shadows. Tested in Nvidia and AMD, did not test on Intel. Subscribers can get the latest beta in the private forum here.
  11. Josh

    Multi-monitor Support

    -Yes. -A monitor has a position relative to the other monitors. They all make up one big virtual screen. -I’m not sure yet.
  12. Use it for anything you like. ______ __________ ______ 2.m4a
  13. New commands in Turbo Engine will add better support for multiple monitors. The new Display class lets you iterate through all your monitors: for (int n = 0; n < CountDisplays(); ++n) { auto display = GetDisplay(n); Print(display->GetPosition()); //monitor XY coordinates Print(display->GetSize()); //monitor size Print(display->GetScale()); //DPI scaling } The CreateWindow() function now takes a parameter for the monitor to create the window on / relative to. auto display = GetDisplay(0); Vec2 scale = display->GetScale(); auto window = CreateWindow(display, "My Game", 0, 0, 1280.0 * scale.x, 720.0 * scale.y, WINDOW_TITLEBAR | WINDOW_RESIZABLE); The WINDOW_CENTER style can be used to center the window on one display. You can use GetDisplay(DISPLAY_PRIMARY) to retrieve the main display. This will be the same as GetDisplay(0) on systems with only one monitor.
  14. In Turbo, I switched this to a uint64_t value. On Windows, internally, the function uses timeGetTime(). However, this function returns a DWORD value, which is an unsigned 32-bit integer. This is actually pretty surprising. For games and even game servers, it is unlikely to cause problems but I can imagine a lot of other applications that run for months or years at a time that would encounter problems with this.
  15. Texture loading plugins allow us to move some big libraries like FreeImage into separate optional plugins, and it also allows you to write plugins to load new texture and image formats. To demonstrate the feature, I have added a working VTF plugin to the GMF2 SDK. This plugin will load Valve texture files used in Source Engine games like Half-Life 2 and Portal. Here are the results, showing a texture loaded directly from VTF format and also displayed in Nem’s nifty VTFEdit tool. Just like we saw with the MD3 model loader, loading a texture with a plugin is done by first loading the plugin, and then the texture. (Make sure you keep a handle to the plugin or it will be automatically unloaded.) auto vtfloader = LoadPlugin("Plugins/VTF.dll"); auto tex = LoadTexture("Materials/HL2/gordon.vtf”); This will be included in the next update to the Turbo Game Engine update, and at that point there is nothing stopping you from creating your own plugins. I hope to someone smart write a plugin for Crunch .crn files, which could cut the size of your game's distribution files down by half. Unlike the GMF2 model format, which provides fast loading of large model files, my internal texture format ("GTF2") has no advantage over other texture formats, and I do not plan to make standalone files in this format. I recommend using DDS files for textures, using BC7 compression for most images and BC5 for normal maps.
  16. Metalness / roughness will do this.
  17. @martyj Currently there is a bug that randomly makes the whole terrain black. Probably texture data not being sent correctly to the GPU. I need to fix that, and I might implement directional light shadows before an update, if they don't take too much time.
  18. I wanted to work on something a bit easier before going back into voxel ray tracing, which is another difficult problem. "Something easier" was terrain, and it ended up consuming the entire month of August, but I think you will agree it was worthwhile. In Leadwerks Game Engine, I used clipmaps to pre-render the terrain around the camera to a series of cascading textures. You can read about the implementation here: This worked very well with the hardware we had available at the time, but did result in some blurriness in the terrain surface at far distances. At the time this was invented, we had some really severe hardware restrictions, so this was the best solution then. I also did some experiments with tessellation, but a finished version was never released. New Terrain System Vulkan gives us a lot more freedom to follow our dreams. When designing a new system, I find it useful to come up with a list of attributes I care about, and then look for the engineering solution that best meets those needs. Here's what we want: Unlimited number of texture layers Pixel-perfect resolution at any distance Support for tessellation, including physics that match the tessellated surface. Fast performance independent from the number of texture layers (more layers should not slow down the renderer) Hardware tessellation is easy to make a basic demo for, but it is hard to turn it into a usable feature, so I decided to attack this first. You can read my articles about the implementation below. Once I got the system worked out for models, it was pretty easy to carry that over to terrain. So then I turned my attention to the basic terrain system. In the new engine, terrain is a regular old entity. This means you can move it, rotate it, and even flip it upside down to make a cave level. Ever wonder what a rotated terrain looks like? Now you know. You can create multiple terrains, instead of just having one terrain per world like in Leadwerks. If you just need a little patch of terrain in a mostly indoor scene, you can create one with exactly the dimensions you want and place it wherever you like. And because terrain is running through the exact same rendering path as models, shadows work exactly the same. Here is some of the terrain API, which will be documented in the new engine: shared_ptr<Terrain> CreateTerrain(shared_ptr<World> world, const int tilesx, const int tiles, const int patchsize = 32, const int LODLevels = 4) shared_ptr<Material> Terrain::GetMaterial(const int x, const int y, const int index = 0) float Terrain::GetHeight(const int x, const int y, const bool global = true) void Terrain::SetHeight(const int x, const int y, const float height) void Terrain::SetSlopeConstraints(const float minimum, const float maximum, const float range, const int layer) void Terrain::SetHeightConstraints(const float minimum, const float maximum, const float range, const int layer) int Terrain::AddLayer(shared_ptr<Material> material) void Terrain::SetMaterial(const int index, const int x, const int y, const float strength = 1.0, const int threadindex = 0) Vec3 Terrain::GetNormal(const int x, const int y) float Terrain::GetSlope(const int x, const int y) void Terrain::UpdateNormals() void Terrain::UpdateNormals(const int x, const int y, const int width, const int height) float Terrain::GetMaterialStrength(const int x, const int y, const int index) What I came up with is flexible it can be used in three ways. Create one big terrain split up into segments (like Leadwerks Engine does, except non-square terrains are now supported). Create small patches of terrain to fit in a specific area. Create many terrains and tile them to simulate very large areas. Updating Normals I spent almost a full day trying to calculate terrain normal in local space. When they were scaled up in a non-linear scale, the PN Quads started to produce waves. I finally realized that normal cannot really be scaled. The scaled vector, even if normalized, is not the correct normal. I searched for some information on this issue, but the only thing I could find is a few mentions of an article called "Abnormal Normals" by someone named Eric Haines, but it seems the original article has gone down the memory hole. In retrospect it makes sense if I picture the normal vectors rotating instead of shifting each axis. So bottom line is that normal for any surface have to be recalculated if a non-uniform scale is used. I'm doing more things on the CPU in this design because the terrain system is more complex, and because it's a lot harder to get Vulkan to do anything. I might move it over to the GPU in the future but for right now I will stick with the CPU. I used multithreading to improve performance by a lot: Physics Newton Dynamics provides a way to dynamically calculate triangles for collision. This will be used to calculate a high-res collision mesh on-the-fly for physics. (For future development.) Something similar could probably be done for the picking system, but that might not be a great idea to do. Materials At first I thought I would implement a system where one terrain vertex just has one material, but it quickly became apparent that this would result in very "square" patterns, and that per-vertex blending between multiple materials would be needed. You can see below the transitions between materials form a blocky pattern. So I came up with a more advanced system that gives nice smooth transitions between multiple materials, but is still very fast: The new terrain system supports up to 256 different materials per terrain. I've worked out a system that runs fast no matter how many material layers you use, so you don't have to be concerned at all about using too many layers. You will run out of video memory before you run out of options. Each layer uses a PBR material with full support for metalness, roughness, and reflections. This allows a wider range of materials, like slick shiny obsidian rocks and reflective ice. When combined with tessellation, it is possible to make snow that actually looks like snow. Instancing Like any other entity, terrain can be copied or instantiated. If you make an instance of a terrain, it will use the same height, material, normal, and alpha data as the original. When the new editor arrives, I expect that will allow you to modify one terrain and see the results appear on the other instance immediately. A lot of "capture the flag" maps have two identical sides facing each other, so this could be good for that. Final Shots Loading up "The Zone" with a single displacement map added to one material produced some very nice results. The new terrain system will be very flexible, it looks great, and it runs fast. (Tessellation requires a high-end GPU, but can be disabled.) I think this is one of the features that will make people very excited about using the new Turbo Game Engine when it comes out.
  19. Probably the driver I think. It’s being performed on the GOU which should make it super smooth
  20. Now intermittently hitting 100% CPU usage on an 8-core processor.

  21. The reason four threads was less than 25% the speed of one is because some calculations were being skipped. I fixed that and the numbers are a little higher now, but still form the same curve.
  22. Multithreading is very useful for processes that can be split into a lot of parallel parts, like image and video processing. I wanted to speed up the normal updating for the new terrain system so I added a new thread creation function that accepts any function as the input, so I can use std::bind with it, the same way I have been easily using this to send instructions in between threads: shared_ptr<Thread> CreateThread(std::function<void()> instruction); The terrain update normal function has two overloads. Once can accept parameters for the exact area to update, but if no parameters are supplied the entire terrain is updated: virtual void UpdateNormals(const int x, const int y, const int width, const int height); virtual void UpdateNormals(); This is what the second overloaded function looked like before: void Terrain::UpdateNormals() { UpdateNormals(0, 0, resolution.x, resolution.y); } And this is what it looks like now: void Terrain::UpdateNormals() { const int MAX_THREADS_X = 4; const int MAX_THREADS_Y = 4; std::array<shared_ptr<Thread>, MAX_THREADS_X * MAX_THREADS_Y> threads; Assert((resolution.x / MAX_THREADS_X) * MAX_THREADS_X == resolution.x); Assert((resolution.y / MAX_THREADS_Y) * MAX_THREADS_Y == resolution.y); for (int y = 0; y < MAX_THREADS_Y; ++y) { for (int x = 0; x < MAX_THREADS_X; ++x) { threads[y * MAX_THREADS_X + x] = CreateThread(std::bind((void(Terrain::*)(int, int, int, int)) & Terrain::UpdateNormals, this, x * resolution.x / MAX_THREADS_X, y * resolution.y / MAX_THREADS_Y, resolution.x / MAX_THREADS_X, resolution.y / MAX_THREADS_Y)); } } for (auto thread : threads) { thread->Resume(); } for (auto thread : threads) { thread->Wait(); } } Here are the results, using a 2048x2048 terrain. You can see that multithreading dramatically reduced the update time. Interestingly, four threads runs more than four times faster than a single thread. It looks like 16 threads is the sweet spot, at least on this machine, with a 10x improvement in performance.
  23. A similar technique for terrain reduced system memory by 130 mb on a 2048x2048 terrain.
  24. What I mean is GTK and some other Linux libs that change with each version of Linux. There is another reason to make components optional, and that is because we can more easily update software for enterprise customers if they can skip optional components. Steam and GA would both be good candidates to make as a plugin, though I am not sure yet exactly how it would work.
  25. I tested a 1.5 million poly mesh and the BSP generation time was about three seconds. Not terrible given the size, but I would like to completely eliminate that annoying delay.
