GUI Tutorial

Entries in this blog

Default Script Fixes

There is a problem with the default TextArea.lua widget script. Your game will crash when you click on an empty TextArea. Fix: look for the Function "Script:GetCaretCoord(caret)" after: local text = self.lines[self.currentline]--self.widget:GetText() add: if text == nil then return 0 end     More will be added when/if discovered...

GorzenDev

GorzenDev

Custom Widgets

Remember that a widget's behaviour is dictated by the script that is attached to it. Well its that simple just use a custom script for your widget and your done. I will show you how to create a simple ColorLabel. First copy the default Label.lua script and rename it to Colorlabel.lua Now lets make some changes in your Colorlabel.lua so open it up. We will add 2 variables to the script called bordercolor and textcolor they will be of type Vec4(). Script.bordercolor = Vec4(0.2,0.2,0

GorzenDev

GorzenDev

Adding/Using Widgets

Previously we created a custom class and a basic GUI. Now its time to add some basic widgets to our class and show how to use them.   Lets start with a simple Panel that has a Label, a TextField and a Button. // UI_Interface.h Widget* panel = NULL; Widget* label = NULL; Widget* textField = NULL; Widget* button = NULL; // UI_Interface.cpp //create gui //.... // //panel = Widget::Panel(guiScale * 100, guiScale * 100, guiScale * 300, guiScale * 80, gui->GetBase()); panel = Widge

GorzenDev

GorzenDev

Basic GUI Creation

Bare with me im not a very good story teller  . I will not be focusing on basic leadwerks usage and assume the reader knows a thing or 2 about leadwerks. So lets start with the basics, Create a window and context. bool App::Start() { window = Leadwerks::Window::Create("GUI Tutorial", 0, 0, 1024, 768); context = Leadwerks::Context::Create(window); return true; } bool App::Loop() { if (window->Closed() || window->KeyHit(Key::Escape)) return false; return true; } Now

GorzenDev

GorzenDev

×
×
